How to Install a Cleated Conveyor?

conveyor beltsindia
Dec 4, 2025
4 min read

Installing‍‌‍‍‌‍‌‍‍‌ a cleated conveyor might look really tough, but if you have a proper plan and take the right steps, it becomes very easy and safe. Normally, a cleated conveyor is used to transport the materials in a vertical direction; hence, the installation has to be done in such a way as to allow a smooth operation and to ensure that the belt is not worn out too quickly.

There is a simple, step-by-step guide below that gives an easy and practical explanation of how to install a cleated conveyor belts.

1. Understand the Conveyor Layout It is necessary to get a full understanding of the conveyor layout before the installation. This means that you must know:

The area where the conveyor is going to be set up
The length and width of the conveyor frame
The kind of cleated belt you are going to use
The material flow direction

Study the technical drawings or the layout plans. Ensure that the place is clean, and there is enough space to work safely. Get rid of any obstacles that may interfere with the installation.

2. Prepare the Tools and Materials

Have all the tools and hardware that you will need. The list of common items may include:

Spanners and wrenches
Screwdrivers
Alignment tools
Belt fasteners (if required)
Tensioning tools
Safety gear (gloves, helmet, shoes)

3. Install the Conveyor Frame

Begin with the installation of the conveyor frame:

Put down the main frames on the floor as per the layout.
Attach the legs or the support stands firmly.
Check if the frame is level.
Later, when the belt is put on, it will not be able to track properly if the frame is tilted.
Tighten all nuts and bolts properly.

Without a firm frame, it will be almost impossible to have a conveyor that will operate without ‍‌‍‍‌‍‌‍‍‌problems.

4.‍‌‍‍‌‍‌‍‍‌ Fit the Pulleys and Rollers

After that, install the head pulley, tail pulley, and idler rollers: The head pulley is at the discharge end. The tail pulley is at the loading end. Idlers support the belt along its length. Make sure: The pulleys are perfectly aligned in a straight line. The rollers rotate without any noise. The bearings are lubricated and fixed properly. Misaligned pulleys are the most frequent cause of belt tracking problems.

5. Position the Cleated Conveyor Belt

Now, you should put the cleated belt on the conveyor:

Unroll the belt gradually on a clean surface.
Check the direction of the cleats; they should be facing upward when installed.
Get the belt ready by lifting it with the help of others so as not to bend the cleats.
Put the belt on the pulleys and rollers.

Make sure the cleats are not getting damaged while you pull the belt onto the frame.

6. Join the Belt Ends

If the belt is open-ended, you need to join it. The methods are two:

Mechanical fasteners: Hot or cold vulcanization.

Mechanical joining is quicker, while vulcanized joints are stronger and smoother.

Choose the method that your belt supplier recommends.

7. Adjust the Belt Tension.

Tensioning is a very important moment: Too loose → belt slips. Too tight → belt and bearings wear out. With the tensioning bolts at the tail pulley, gradually tighten the belt.

Also, as you tension the belt, do it manually to check if the conveyor rotates smoothly.

8. Check and Correct Belt Tracking.

Belt movement at a slow speed should be checked by manual rotation or low motor speed. Look at the way it moves: If the belt moves to one side, then you need to adjust the tracking screws. Adjustments should be made in small increments; big adjustments can worsen the situation. Check that the cleats are going through the rollers and guides without bumps. A correctly tracked belt runs in the center and does not rub against the sides.

9. Install the Motor and Electrical Components.

Put the drive motor and gearbox on the frame:

Make the motor shaft and the head pulley shaft in line.
Wiring for power should be done according to safety standards.
Before switching on, check all the connections. Always get a qualified electrician to do the wiring.

10. Test Run the Conveyor Lastly, do a test run:

Run the conveyor at low speed.
Check the belt movement, cleat clearance, and noise levels.
Put on a small amount of material and test performance.

Make the final adjustments if necessary.

The successful test run is a guarantee that the conveyor is good to go for full ‍‌‍‍‌‍‌‍‍‌operation.

Conclusion

It‍‌‍‍‌‍‌‍‍‌ might appear that putting in a cleated conveyor belts is difficult; however, with proper preparation and the correct equipment, it turns out to be very easy. You can carry out the installation safely and get the machine up and running in no time by adhering to the instructions in this manual.
